Display Philips PPDS

Display Philips PPDS

When you turn on the display for the first time, the guided setup for configuring the main settings will begin.

Disable Automatic Sleep Mode

Enter the Administrator Menu and select.
“Settings” -> “Display”, then set “Sleep Mode”  to OFF and “Screensaver” to OFF.
"Settings"->"Security", then set “Unknown Sources” to True.

Install Livesignage

You can choose between two alternative options to download the app.

Option 1 - CMND & Deploy

Enter the Administrator Menu, open the CMND & Deploy app, and enter the URL: https://myls.io/philips/ls.apk
Press the "GO" button to start the download.
Once the download is complete, return to the Administrator Menu and navigate to:
"Storage" → "Internal Storage" → "Download"
Open the ls.apk file and follow the on-screen instructions to complete the installation.

Option 2 - USB Flash Drive

Download the ls.apk file from the following URL: https://myls.io/philips/ls.apk
Save the file onto a USB flash drive. Insert the USB flash drive into the display's USB port. Enter the Administrator Menu and select "Storage".
Choose the USB flash drive and locate the ls.apk file.
Open the file and follow the on-screen instructions to complete the installation.

Once completed, you will see the Livesignage logo on your display.

Connecting the Display ​to Livesignage

After a few seconds, a numeric code will appear on the display.
